제품 상세 정보:
|
|
| 원래 장소: | 중국 (본토) |
|---|---|
| 브랜드 이름: | YT |
| 모델 번호: | U30-6 |
|
결제 및 배송 조건:
|
|
| 최소 주문 수량: | 1 개 PC |
| 가격: | negotiable |
| 포장 세부 사항: | 수출 포장 |
| 배달 시간: | 7-30 일 |
| 지불 조건: | l/c, t/t |
| 공급 능력: | 10000 PCS/월 |
|
상세 정보 |
|||
| 재료: | 40Mn2 또는 35MnBH 강철 | 기술: | 단조 |
|---|---|---|---|
| 품질: | 열처리 로크웰C경도 40-55 | HRC 깊이: | 4-10 밀리미터 |
| 색상: | 요구된 검거나 고객 | 보증 시간: | 12-18개월 |
| 마치다: | 매끄러운 | 지불 조건: | 협상 가능 |
| 강조하다: | Heavy Duty Track Chain Link,OEM Replacement Excavator Track Chain,Self-Lubricated System Undercarriage Track Chain |
||
제품 설명
Our facility employs sophisticated horizontal and vertical CNC systems for operations like cutting, boring, tapping, and milling, all aimed at enhancing the precision and reliability of each part. This meticulous approach ensures the alignment and fit of assembled components are spot-on, thereby extending the operational lifespan of the parts and reducing the cost per unit produced.
Track link is made of 35 MNB forged special steel that is reinforced with structure technology and advanced heat treatment process, which ensures maximum strength and abrasion resistance to the product. The self-lubricated system enhances the service life of track chain bearing remarkably.
| Suitable Model | P | A | B | C | E | F | H | K | L |
|---|---|---|---|---|---|---|---|---|---|
| U30-6/EX30/EX35/PC30 | 101.6 | 55 | 55 | 22 | 10.5 | 35 | 76 | 63 | 26 |
| SK025/SK30/SK32 | 101.6 | 65 | 65 | 22 | 10.5 | 45 | 86 | 63 | 26 |
| PC20 | 101.6 | 52 | 52 | 22 | 10.5 | 32 | 73 | 65 | 28 |
| PC60-3/5/DBC8060 | 135 | 99 | 72 | 43.2 | 12.5 | 45 | 105 | 75 | 35 |
| EX40/EX45 | 135 | 104 | 80 | 46 | 12.5 | 52 | 105 | 65 | 30 |
| PC100-2/PC100-3/HD350 | 154 | 112.4 | 82.4 | 57 | 14.5 | 49.4 | 124.4 | 87 | 40 |
| R200 | 171.45 | 144.5 | 125.4 | 58.7 | 16.5 | 87.7 | 171.7 | 101.6 | 42.8 |
| EX100/R900/E120 | 171.45 | 108 | 108 | 60.3 | 16.5 | 68 | 144.8 | 95 | 44 |
| PC120/130-6/PC150 | 175 | 102.4 | 86.4 | 57 | 16.5 | 48.4 | 124.4 | 90 | 42 |
| PC400-5/EX400-5 | 216 | 184 | 146 | 76.2 | 24.5 | 104 | 211.2 | 129 | 59 |
| EX300-6/EX330-5/PC300 | 216 | 178.4 | 140.4 | 76.2 | 22.5 | 99 | 198.2 | 116 | 52 |
The models above are just for reference. We can supply more products as per your requirements. Please feel free to send us your inquiry or email if you have any requirements.
We are an industry and trade integration business, our factory located in Quanzhou, and our sales department is in the center of Xiamen city.
Sample is free, but the customer needs to pay for shipping.
We usually accept T/T or L/C. Other terms also could be negotiated.
It depends on what you are buying. Normally, our minimum order is USD5000. One 20' full container and LCL container (less than a container load) can be acceptable.
FOB Xiamen or any Chinese port: 35-45 days. If there are any parts in stock, our delivery time is only 7-10 days.
We have a perfect QC system for the perfect products. A team who will detect the product quality and specification piece carefully, monitoring every production process until packing is complete, to ensure product safety into the container.
